Manual Embossing Machine,Metal Embosser Alphanumeric Plate Stamping Dog Tag Embossing Marking Machine Printer with 2.0mm-5.0mm Print Wheel
About this product
*★Emboss on all types of aluminum, copper, stainless steel for mechanical, electrical, pumps, valves, automobiles, motorcycles, electrical appliances.
*★Widely used:It embosses variable parameters: such as dog tag, specific model, date, batch number, serial number, serial number and so on.
*★Printing content including: A B C D E F G H I J K L M N O P Q R S T U UV W X Y Z 123456789 x / -.
*★Steel plate: The alloy steel rotary plate heat-treated by high-frequency quenching is printed with a certain depth (0.1∽0.3mm deep) letters or numbers on the metal sign under the action of external force (hand pressure or rubber hammer)
*★The utility model has the advantages of small volume, light weight, convenient and convenient operation, neat printing and writing, uniform and clear lines, and various font sizes.
Description
Description:
Steel plate: The alloy steel rotary plate heat-treated by high-frequency quenching is printed with a certain depth (0.1?0.3mm deep) letters or numbers on the metal sign under the action of external force (hand pressure or rubber hammer);
The steel dial can be rotated to the desired letter or digital automatic card position, and the word conversion can be easily realized;
The marking position and the line spacing are manually adjusted by the mechanical mechanism;
Different word heights can be achieved by replacing the dial;
Various shape signs with a shape length of less than 185 mm and a height of less than 2 mm can be imprinted.
Specifications:
The utility model has the advantages of small volume, light weight, convenient and convenient operation, neat printing and writing, uniform and clear lines, and various font sizes.
Steel plate material; winding steel 12 Hardness: 58-60HV Straight: 84mm Inner hole: 14mm.
No. 2; Height 2 mm width 1.2 mm tooth width 4 mm thickness 6 mm.
NO. 2.5 ;Height 2.5 mm wide 1.4 mm tooth width 4 mm thickness 6 mm.
No. 3 ;Height 3 mm width 1.6 mm Tooth width 4 mm Thickness 6 mm.
No. 4; Height 4 mm Width 2.1 mm Tooth width 4.5 mm Thickness 6 mm.
No. 5; Height 5 mm Width 2.6 mm Tooth width 4.5 mm Thickness 6 mm.
Note: small characters in the number (1) small characters in the symbol (.) in English small characters (I) large characters (MW)
The word wheel number contains:
Capital letters: ABCDEFGHIJKLMNOPQRSTUVWXYZ
Arabic numerals: 1234567890
Simple symbol: ·×/- (can be customized special symbols)
